This compact 24V Power Supply is designed for LED strip lights, low voltage LED bulbs and small 24V DC lighting installations. With a 36W rated output, it is suitable for LED circuits requiring a reliable constant voltage power source.
The GP-CVP036N-24V-T12 provides 24V DC output with up to 1.5A current, making it suitable for 24V LED strip lighting, cabinet lighting, display lighting and decorative LED installations.
For LED strip lights, always check the wattage per metre before installation. This 36W power supply can operate LED loads up to 36W in total. For example, it can support up to 5 metres of 7.2W per metre LED strip, provided the total load does not exceed the rated output.
The power supply uses a constant voltage design, making it suitable for 24V LED products that require a stable DC output. The fully isolated plastic case and Class II design provide safe operation without an earth connection.
Input and output wiring is completed through 2P screw terminal blocks, making installation simple and avoiding the need for special connectors. The compact body is easy to position inside cabinets, display units and other tight installation spaces.
| Model | GP-CVP036N-24V-T12 |
| Product Type | 24V Power Supply / Constant Voltage LED Driver |
| Output Voltage | 24V DC |
| Rated Output Current | 0-1.5A |
| Rated Output Power | 36W |
| Voltage Tolerance | ±5% |
| Ripple and Noise | 240mVp-p max. |
| Efficiency | 85% minimum at 230VAC full load |
| Input Voltage Range | 90-264VAC |
| Rated Input Voltage | 100-240VAC |
| Frequency Range | 47-63Hz |
| AC Current | 1A at 115VAC / 0.5A at 230VAC |
| Inrush Current | <30A at 115VAC / <60A at 230VAC |
| No Load Consumption | <0.5W at 230VAC |
| Protection | OCP, SCP, OTP and OVP |
| Short Circuit Protection | Hiccup mode with automatic recovery after fault is removed |
| Over Current Protection | 110%-150% constant current limiting with automatic recovery |
| Operating Temperature | -20°C to 40°C |
| Operating Humidity | 20% to 90% RH non-condensing |
| Storage Temperature | -20°C to +80°C |
| Connection | Input and output 2P screw terminal blocks |
| Terminal Wire Range | 0.75-1.5mm² input and output |
| Dimensions | 96 x 44.3 x 30mm |
| Weight | 150g |
| Safety Standards | EN61347-1, EN61347-2-13 |
| EMC Standards | EN55015, EN61000-4-2/3/4/5/6/11, EN61547, EN61000-3-2 Class C |
|
Model No. |
GP‐CVP036N‐24V‐P02 |
|
|
Output |
DC Voltage Range |
24V |
|
Rated Current |
0‐1.5A |
|
|
Rated Max. Power |
36W |
|
|
Voltage Tolerance |
± 5% |
|
|
Ripple & Noise (Max.) note.2 |
240 mVp‐p |
|
|
Efficiency (Min) |
85% at 230VAC full load |
|
|
Set up Time (Max) |
< 1S / 115VAC at full load / < 0.5S / 230VAC at full load |
|
|
Input |
Rated Voltage |
100 ‐ 240VAC |
|
Voltage Range |
90‐264VAC |
|
|
Frequency Range |
47 Hz ~ 63 Hz |
|
|
AC Current (Max.) |
1A at 115VAC /0.5A at 230VAC |
|
|
Inrush Current (Max.) |
< 30A at 115VAC /< 60A at 230VAC |
|
|
Leakage Current |
< 0.25mA / 240VAC |
|
|
No Load Consumption |
＜0.5W at 230VAC |
|
|
Protections |
Over Current |
110% ‐ 150% Constant current limiting, auto‐recovery |
|
Short Circuit |
Hiccup mode, recovers automatically after fault condition is removed |
|
|
Over Temperature |
Shut down o/p voltage, recovers automatically after temperature goes down. |
|
|
Over Voltage |
29‐33V |
|
|
Protection type: Shut down o/p voltage, recovers automatically after voltage goes down. |
||
|
Environment |
Operation Temp. |
‐20°C ~ 40°C (Refer to output load derating curve) |
|
Operation Humidity |
20% ~ 90% RH non‐condensing. |
|
|
Storage Temp & Humidity |
‐20 ~ +80°C ,10% ~ 90% RH |
|
|
Safety & EMC |
Safety Standards |
EN61347‐1,EN61347‐2‐13; |
|
Withstand Voltage |
I/P ‐ O/P: 3.75K VAC |
|
|
Isolation Resistance |
I/P ‐ O/P: 100M ohms / 500VDC at 25°C |
|
|
EMI Conduction & radiation |
meet Compliance to EN55015; FCC PART15 CLASSB |
|
|
EMS immunity |
meet Compliance to EN61000‐4‐2,3,4,5,6,11;EN61547,EN61000‐3‐2 CLASS C |
|
|
Connection |
Input |
UL rated, 18 AWG x 2 C ( 150 mm) |
|
Output |
UL rated, 18 AWG x 2 C ( 150 mm) |
|
|
Others |
MTBF |
100K hours min. @Ta=25 °C |
|
Dimension (L x W x H) |
110 x 35 x 25mm; 155g/pcs |
|
|
Note |
|
|
