The GP-CVP040N LED dimmable driver is a high-performance constant voltage power supply designed for LED strip lighting systems. With a stable 24V DC output and 40.8W rated power, it provides reliable and efficient operation for both residential and commercial lighting installations.
In addition, this LED dimmable driver supports TRIAC phase-cut dimming, working seamlessly with both leading edge and trailing edge dimmers. Therefore, it delivers smooth dimming from 5% to 100% without flicker.
Designed for compatibility, this LED dimmable driver operates with a wide input voltage range of 205–256VAC and supports standard AC dimming systems. As a result, it is suitable for use in homes, restaurants, retail environments and architectural lighting.
Moreover, the low ripple output (0.6Vp-p for 24V model) ensures stable lighting with minimal flicker, improving visual comfort and LED lifespan. :contentReference[oaicite:0]{index=0}
The fully sealed housing offers an IP65 rating, making this LED dimmable driver suitable for both indoor and outdoor installations. It is resistant to dust and water jets, allowing installation in demanding environments.
Furthermore, the fully isolated and potted design enhances durability and thermal performance.
This LED dimmable driver includes comprehensive safety protections such as over-voltage, over-current, short-circuit and over-temperature protection. In case of fault, the unit automatically recovers once normal conditions are restored.
| Model | GP-CVP040N-24VH-P02 |
| Type | Constant Voltage LED Dimmable Driver |
| Output Voltage | 24V DC |
| Output Current | 1.7A |
| Power | 40.8W |
| Dimming Type | TRIAC (Leading & Trailing Edge) |
| Dimming Range | 5% – 100% |
| Input Voltage | 220 – 240V AC |
| Voltage Range | 205 – 256V AC |
| Efficiency | Up to 84% |
| Ripple & Noise | 0.6Vp-p |
| IP Rating | IP65 |
| Operating Temperature | -20°C to +50°C |
| Lifetime | 100,000 hours (MTBF) |
| Dimensions | 107.5 x 43.5 x 32 mm |
This LED dimmable driver is suitable for indoor and outdoor use. It should be installed in accordance with electrical regulations and paired with compatible TRIAC dimmers for optimal performance.
|
Model No. |
GP-CVP040N-12VH-P02 |
GP-CVP040N-24VH-P02 |
|
|
Output |
Voltage Range |
12VDC |
24VDC |
|
Ripple & Noise (Max.) |
0.8Vp-p |
0.6Vp-p |
|
|
Voltage Tolerance |
± 5% |
± 5% |
|
|
Dimming Range |
5%~100% |
5%~100% |
|
|
Rated Current |
3.4A |
1.7A |
|
|
Rated Power |
40.8W |
40.8W |
|
|
Efficiency (Typ.) |
82% |
84% |
|
|
Set up Time (Max.) |
0.5S / 230VAC at full load |
||
|
Input |
Rated Voltage |
220~240VAC |
|
|
Voltage Range |
205~256VAC |
||
|
Frequency Range |
50/60 Hz |
||
|
AC Current (Max.) |
0.5A at 230VAC |
||
|
Power Factor |
> 0.45 at 230VAC with full load. |
||
|
Inrush Current (Typ.) |
Cold Start 50A at 230VAC |
||
|
Leakage Current (Typ.) |
<1mA / 230VAC |
||
|
Protections |
Over Voltage |
120 % - 150% Output voltage limiting, auto-recovery |
|
|
Over Current |
120% - 150% Constant current limiting, auto-recovery |
||
|
Over Temperature |
110°C - 125°C Temperature limiting, auto-recovery |
||
|
Short Circuit |
Hiccup mode, recovers automatically after fault condition is removed |
||
|
Others |
MTBF |
100K hours min. @Ta=25°C |
|
|
Dimension(L x W x H) |
107.5 x 43.5 x 32 mm; 240g/pcs |
||
