Upgrade older fluorescent fittings with this high-performance LED gear tray from Voltacon. Designed as a practical retrofit solution, this 18W LED gear tray replaces traditional 28W and 36W 2D CFL lamps and helps modernise existing round ceiling and wall lights without changing the whole fitting.
This LED gear tray is built on a durable metallic tray and includes a built-in driver for straightforward installation. It is ideal for electricians, maintenance teams and lighting upgrades where a reliable retrofit is needed. Because the tray is designed for fittings that previously used a fluorescent 2D lamp, it offers a simple route to lower energy use, longer service life and improved light quality.
The Voltacon LED gear tray offers excellent flexibility for lighting refurbishment projects. It can be fitted into many round ceiling or wall luminaires that were originally designed for 2D fluorescent lamps. As a result, it is a very useful option for residential blocks, corridors, utility areas, stairwells, offices and commercial buildings.
A compact yet powerful LED driver is mounted directly on the tray, while the fully insulated junction box supports safe mains connection. In addition, the current version includes a three-way power block for switched live, neutral and earth, helping to simplify installation.
This retrofit LED gear tray also features a built-in 3-way switch for colour temperature selection. You can choose warm white, natural white or cool white to suit the application. This makes the fitting more adaptable for different spaces and user preferences.
The tray uses 250 SMD2835 LED chips arranged in 5 concentric circles to create a wide and even light output. With 1800 lumens and a 120 degree beam angle, this LED gear tray provides smooth illumination across the diffuser and reduces dark spots often seen with older lamp technology.
Furthermore, the fitting is flicker free, which helps improve visual comfort in everyday environments. Combined with a long 50,000 hour lifespan, this makes it a dependable long-term replacement for outdated fluorescent gear trays and 2D lamp systems.
If you are looking for a dependable LED gear tray to replace a fluorescent 2D lamp setup, this model offers an efficient and professional solution. It reduces maintenance, improves energy efficiency and provides switchable light colour in one compact retrofit board.
| Fitting | 2D / 4 pin | Luminous flux | 1800lm |
| Wattage (rated) | 18W | Colour rendering index | >80 |
| Voltage | 100-265V | Typical efficiency | 100lm/W |
| Line frequency | 50/60Hz | Beam angle | 120° |
| Average lifetime | 50,000 hours | Current | 250mA |
| Colour temperature | 3000K / 4000K / 5000K | Dimensions | 262mm diameter |
| Warm white | 3000K | Power factor | 0.95 |
| Natural white | 4000K | Dimmable | No |
| Cool white | 5000K | Warranty | 5 years |
| Operating temperature | -20°C to 45°C | Certification | TUV, RoHS, CE, UL |
