The Voltacon 40W LED dimmable driver is a high-quality constant current power supply designed for a wide range of LED lighting systems. It supports both leading edge (TRIAC) and trailing edge (ELV) dimming, ensuring smooth and flicker-free light control in residential and commercial installations.
In addition, the output current can be easily adjusted via integrated DIP switches, allowing installers to match the driver to different LED loads with precision and flexibility.
This LED dimmable driver works with standard phase-cut dimmers, including both leading and trailing edge types. Therefore, it ensures stable dimming performance across a wide range of lighting control systems.
Moreover, the driver offers a full dimming range from 0 to 100%, delivering consistent brightness control without flicker.
The driver supports a wide adjustable output current range from 300mA up to 1400mA using DIP switches. As a result, it can power various LED luminaires such as downlights, spotlights and panel lights.
According to the datasheet, the unit maintains a current tolerance of ±5% and provides stable output across different load conditions. :contentReference[oaicite:0]{index=0}
With an efficiency of up to 80% and a power factor greater than 0.93, this LED dimmable driver ensures efficient energy usage and reliable operation under full load conditions.
Additionally, the built-in active PFC function improves overall system performance and reduces electrical losses.
This LED dimmable driver includes comprehensive protection features such as short circuit, overload and over temperature protection. In case of abnormal conditions, the driver automatically recovers once the fault is cleared.
Furthermore, the Class II design and fully enclosed housing provide safe operation in indoor environments.
| Product Name | Voltacon AC Triac LED Dimmable Driver 40W |
| Power | Up to 40W |
| Output Current | 300mA – 1400mA (Selectable via DIP switch) |
| Output Voltage | 3V – 65V DC |
| Input Voltage | 200 – 240V AC |
| Frequency | 47 – 63Hz |
| Dimming Type | TRIAC / Phase Cut (Leading & Trailing Edge) |
| Dimming Range | 0 – 100% Flicker-Free |
| Power Factor | ≥0.93 |
| Efficiency | Up to 80% |
| Protection | Short circuit, overload, over temperature |
| IP Rating | IP20 (Indoor use) |
| Operating Temperature | -40°C to +60°C |
| Dimensions | 171.5 x 54 x 20 mm |
| Weight | Approx. 225g |
This LED dimmable driver is designed for indoor use only. It should be installed by a qualified professional and placed in a well-ventilated area to ensure proper heat dissipation and long service life.
| Model | EUP45T-1HMC-0 |
|---|---|
| Output | |
| Current | 800mA, 850mA, 900mA, 950mA |
| Voltage | 9-45VDC |
| Power | 36W, 38.25W, 40.5W, 42.75W |
| Current | 1000mA, 1050mA, 1100mA, 1150mA |
| Voltage | 9-45VDC, 9-43VDC, 3-41VDC, 3-39VDC |
| Power | 45W, 45.15W, 45.1W, 44.85W |
| Current accuracy | ±5% |
| No load output voltage | 55VDC Max |
| Output LF current ripple (<120 Hz) | <3% |
| Channels | 1 |
| Input | |
| Voltage | 220-240VAC |
| Frequency | 50/60Hz |
| Current | 0.26A max @ 230VAC |
| Power factor | >0.9 @ 230VAC, full load |
| THD | <20% @ 230VAC, full load |
| Efficiency | 85% @ 230VAC, full load |
| Inrush current | Cold start, 40A (twidth = 24us measured at 50% Ipeak) @ 230VAC |
| Protection | |
| Short circuit protection | Closes output, recovers automatically after fault is removed |
| Overload protection | Output current decreases when voltage is exceeded, recovers automatically when load is reduced |
| Over temperature protection | Shuts down the output, recovers automatically when temperature returns to normal |
| Other Specifications | |
| Dimming | Triac/ELV |
| Dimensions | 137*82*31 mm (L*W*H) |
| G.W. | 240g |
| Working temperature | -20℃ to 50℃ |
| Relative humidity | 20%–90% RH |
